T+A   PA 1260 R LE




Adiofilní integrovaný zesilovač 2 x 150W


                novinka









                      T+A   PA 1260 R LE































                      Číslo produktu:

                            10510






                        Barevné provedení:














































T+A   PA 1260 R LE


Limitovaná poslední kolekce 30 setů legerdární R série


Ručně lakovaná stříbrná /Arctic Silver/ ve vysokém lesku










PA 1260 R - INTEGRATED AMPLIFIER


PA 1260 R audiophile integrated amplifier. Building small, compact integrated amplifiers with superior sound quality is a great art - an art which T+A has mastered like no other company. Like its superbly reviewed predecessor, the PA 1230 R, the PA 1260 R is also assembled from the brilliant components, circuit boards and technologies developed for our pre-amplifiers and power amplifiers. We sanction no compromises, and for this reason the machine achieves exactly the same level of sound quality as these individual modules, and although it offers slightly less output power than the A 1560, it is still capable of delivering a lavish 300 Watts continuous power into 4 Ohms. Even large and critical loudspeakers are tamed and controlled effortlessly by this amplifier. Seven line-level inputs, two tape outputs and one pre-amplifier output make this all-rounder the fabulous heart of a compact High-End system with exceptional sound.

































Specifications








Pre-amplifier stage









Frequency response (+0 –3 dB)




0,5 Hz – 400 KHz








Signal noise ratio













High-level




7 x 107 / 109 dB








Phono MM (optional)




82 / 86 dB








Phono MC (optional)




78 / 82 dB








Subsonic Filter




14 Hz








Total harmonic distortion




< 0,001 %








Intermodulation




< 0,001 %








Channel separation




> 90 dB








Input sensitivity nominal













High-level




250 mV / 20 kOhm








Phono MM (optional




1 – 5 mV / 16 capacitances








Phono MC (optional)




60 – 1000 µV / 16 impedances








Phono module replaced one high-level input









Outputs













Head phone




50 Ohms








2 x Tape




250 mV eff / 100 Ohms








PRE out RCA nominal




1 V eff








maximal




9,5 V eff








Impedance




22 Ohms








PRE out XLR nominal




1,45 V eff








maximal




19,6 V eff








Impedance




22 Ohm








Surround interface (TASI)




built in








Output stage









Nominal output per channel into 8 Ohms




100 Watts








Both channels simultaniously into 4 Ohms




150 Watts








Peak output into 8 Ohms




150 Watts








Peak output into 4 Ohms




290 Watts








Power bandwidth




1 Hz - 300 kHz








Frequency response +0 - 3 dB




1 Hz - 400 kHz








Slew rate




60 V/µs








Damping factor




>500








Signal:noise ratio




>110 dB








Total harmonic distortion




<0,002 %








Reservoir capacity




50000 µF








Mains 110 V/60 Hz or 220/240 V/50 Hz




300 VA








Dimensions (H x W x D)




7,5 x 44 x 39 cm








Weight




7 kg








Finishes




silver aluminium, black








Remote control




incl. FM 100 R








we reserve the right to alter technical specifications
